Product update : A-WZ oil separator, R410A compatible

Product Certifications:

Suzhou A-WZ products are both CE and UL certified.

The following table maps the Mexico produced A_W and A-WZ oil separator products to the Suzhou produced A-WZ oil separator products. Both the A-W and A-WZ series oil separators produced in Mexico will be replaced by the new models from Suzhou as reflected in the same row in the following table.

For example, Mexico made A-WZ 55824 (066135) and A-W 55824 (060933) will both be replaced by Suzhou made A-WZ 55824 (066666).

PS2 Dual Pressure Controls

PS2 Dual Pressure Controls are designed for use on high and
low pressure applications in refrigeration, airconditioning, and
heat pump systems. This control react to changes in either
low or high side pressures, providing single-device control of the
compressor or other electrical device.
Features
• Adjustable pressures and differentials
• Narrow adjustable differential depending on model
• Range and differential pointer in units bar and psig
• Range and differential individually lockable by tab
• High rated SPDT contacts for all versions
• Captive terminal and cover screws
• Manual toggle for system checkout and override
• Factory installed wire bridge for reduced installation effort
• High side convertible from manual to auto reset.
Options
• Different pressure connections
• Automatic and manual reset versions
• Factory set to customer specifi cation
Specifications
• SPDT switch rated for 12FLA and 72LRA at 240VAC and 16FLA
and 96LRA at 120VAC
• Agency approvals include:
UL/CUL fi le number E85974,
CE per (LVD) low voltage directive

PS1 Single Pressure Controls

PS1 Single Pressure Controls are designed for use on high and low
pressure applications in refrigeration, airconditioning and heat
pump systems, providing single-device control of the compressor or
other electrical device.
Features
• Adjustable pressures and differentials
• Narrow adjustable differential depending on model
• Range and differential pointer in units bar and psig
• Range and differential individually lockable by tab
• High rated SPDT contacts for all versions
• Captive terminal and cover screws
• Manual toggle for system checkout and override

Options
• Different pressure connections
• Automatic and manual reset versions
• Factory set to customer specifi cation
Specifications
• SPDT switch rated for 12FLA and 72LRA at 240VAC
and 16FLA and 96LRA at 120VAC
• Agency approvals include:
UL/CUL fi le number E85974
CE per (LVD) low voltage directive
